CONSEW P1206RB-7 Single-Needle Industrial Walking-Foot Sewing Machine. Call For Price 214-749-7991.

Show Room Machine

Single Needle Walking Foot Sewing Machine

Description

Show Room Machine

The Consew P1206RB-7 is a single-needle industrial lockstitch machine designed for upholstery, leatherwork, and other demanding sewing applications. Its compound-feed system coordinates the needle, feed dogs, and walking foot to guide layered materials through the machine. Automatic functions simplify routine sewing tasks and support efficient production. Call For Price 214-749-7991.



Machine Brand MACHINE BRAND:

CONSEW Industrial Sewing Machines

Sewing Machine Model MACHINE MODEL:

CONSEW P1206RB-7

Sewing Machine Description MACHINE DESCRIPTION:

Applications

  • Furniture, automotive, and boat upholstery.
  • Leather, vinyl, canvas, and synthetic materials.
  • Handbags, luggage, and travel accessories.
  • Tents, awnings, tarpaulins, and protective covers.
  • Outdoor apparel, camping gear, and sporting equipment.
  • Coated and laminated fabrics.

Features

  • Compound-feed walking-foot system helps keep material layers aligned.
  • Automatic thread trimming reduces manual cutting between seams.
  • Automatic presser-foot lift assists with positioning and removing work.
  • Automatic backtacking secures the beginning and end of seams.
  • Needle positioning controls where the needle stops.
  • Reverse stitching reinforces selected areas.
  • Large-capacity bobbin reduces the frequency of bobbin changes.
  • Side-loading bobbin provides convenient access.
  • Adjustable upper-thread tension supports different material and thread combinations.
  • Locking stitch regulator helps preserve the selected stitch length.
  • Pump-operated lubrication system allows oil-flow adjustment.
  • Bobbin winding mechanism prepares replacement bobbins.
Techical Specifications TECHNICAL SPECS:
  • Technical Specifications — Consew P1206RB-7
    • Machine type: Industrial flatbed sewing machine.
    • Stitch formation: Single-needle, Type 301 lockstitch.
    • Feeding system: Compound feed combining needle feed, feed dogs, and a walking foot.
    • Maximum stitch length: 7 mm.
    • Needle system: 135 × 17 / DP × 17.
    • Needle-bar stroke: 37 mm.
    • Bobbin size: M-style, large capacity.
    • Hook configuration: Horizontal-axis rotary hook with side-loading bobbin.
    • Lubrication: Pump-driven oil system with adjustable flow.
    • Automatic functions: Thread trimming, backtacking, presser-foot lifting, and needle positioning.
    • Reverse sewing: Included.
Sewing Machine Setup MACHINE SETUP:

This machine ships complete and fully assembled – ready to sew upon arrival.

It includes:

  • Machine Head
  • Tabletop
  • Stand
  • Thread Stand
  • 110 Volt Power SERVO Motor
  • Tools & Manuals



Sewing Machine Voltage MOTOR & VOLTAGE: This machine is equipped with a SERVO motor operating on standard 110 Volts power.
Sewing Machine Warranty WARRANTY: 1 Year Limited Warranty
Sewing Machine Sale Price SALE PRICE: CALL FOR PRICE 214-749-7991
SHIPPING COST: $295.00 Commercial Address

$395.00 Residential Address with Lift Gate Delivery and Appointment

Delivery Time DELIVERY TIME: In stock 3 to 5 Business Day Delivery Window.
icon pdf MACHINE BROCHURE: N/A
Sewing Machine Parts Manual PARTS MANUAL: Ship with the machine









Additional information

Weight 9999 oz
